All prices advertised are cash price.
1022HI without loader $12,117
1022HIL with loader $14,844
1022HILB with loader and backhoe $20,628
1022HIM without loader with 54″ mid mount mower $14,639
1022HILM with loader and 54″ mid mount mower $17,366
1022HILMB with loader and 54″ mid mount mower and backhoe $23,144
Available Bad Boy Implement Ad-Ons:
-
4ft Rotary Cutter (Slip Clutch) – $1,999
-
4ft Rotary Cutter SD (Slip Clutch) – $1,713
-
4ft Box Blade – $964
-
4ft Grader Blade – $756
-
4ft Landscape Rake – $713
-
4ft Rotary Tiller (Forward Till) – $2,627
-
48” Grapple w/ 3rd Function Kit – $2,799
-
42” Pallet Forks – $956
-
3-Point Spreader w/ Cover – $996
-
Tow-Behind Spreader w/ Cover – $1,999
-
Trailer Mover – $441
-
2-Spear Trailer Mover / Hay Fork Combo – $513
-
3-Spear Hay Fork – $656
-
QA Front Hay Spear – $727
The Sub-Compact Powerhouse
- 22 Horsepower
- 617 lbs. Loader Lift Capacity At Pins
- Hydro Max Transmission
- Treadle Style HST Pedals
- Reverse Mount Engine
- 2 Range Transmission
- Independent PTO
- Power Steering
- Selectable 4wd
- Diffirential lock
- 7 Year Powertrain Warranty
- Engine: 3 Cylinder, Water-Cooled, Diesel
- Engine HP @ RPM: 21.5
- Displacement (in.): 60.6
- Number Of Cylinders: 3
- Fuel Tank (gal.): 6.6
- Transmission: HST
- Number Of Speeds: 2 Range
- Clutch: Dry Single Plate
- Brakes: Wet, Multi-Disc
- Type: Power Assisted Hydro-Static
- Total Hydraulic Flow (Power Steering + Implement): 6.3 (2.1+4.2) / 23.8 (8+15.8)
- 3-Point Hitch: Limited Cat 1
- Rear Remote Valve: Optional (Up To 1)
- 3-Point Hitch Lift Capacity @ 24″ Behind Lift Point (lbs.): 679
- Overall Length: 94.2″
- Overall Width: 44.5″
- Overall Height: 86.6″
- Wheelbase: 53.1″
- Minimum Ground Clearance: 8.3″
- Weight: 1,433 lbs.
- Type: Independent
- Rear (Mid) PTO Speed: 540
- PTO HP: 15.4
- Battery: 12 V, 500 CCA
- Alternator: 12 V, 40 A
- IND (Front): 18X8.50-10
- IND (Rear): 26X12-12
- Standard Bucket Size (in.): 48
- Maximum Lift Height (in.): 72.7
- Dig Depth (in.): 4.0
- Lift Capacity To Full Height At Pivot Pin (lbs.): 617
- Breakout Force (lbs.): 1,253
- Shipping Weight (lbs.): 438
- Standard Bucket Size (in.): 12
- Type: Subframe-Mounted, Quick Attach
- Maximum Dig Depth (in.): 66
- Dig Force Bucket (lbs.): 1,975
- Shipping Weight (lbs.): 747
