Premium Series Hydraulic Breakers — Model TF-17
-
Includes 2 Chisel Tools — comes standard
-
Gas Charging Kit Included
-
Warranty — 1 year (excludes wear parts)
Specifications
| Feature | Details |
|---|---|
| Impact Energy Class | 3,500 ft-lb |
| Operating Weight | 2,816 lbs |
| Overall Length | 103 in |
| Required Oil Flow | 110 – 170 LPM /29 – 44 GPM |
| Operating Pressure | 160 – 180 bar / 2,320 – 2,610 PSI |
| Blow Rate | 500 – 740 Long 340 – 590 Short |
| Tool Diameter | 4.6 in |
| Suitable Carrier | 14 – 24 ton (30,865 – 44,093 lbs) |
Important Notice
Warning: Chisel paste must be used with hydraulic breakers. Using high-temperature grease as a substitute will cause damage to breaker components.
Weights may differ based on selected mount styles. Prices and specifications subject to change without notice.
